Electric Bicycle
WY-G04-2025Wangye
WY-G04
The WY-G04 electric bicycle from Wangye (王野) pairs a 1000W motor with a 72V20Ah Lead-acid battery to deliver a top speed of 45km/h and up to 90km of range per charge. Front disc and back drum brakes and 3.00-10 Vacuum tires provide safe, controlled riding. A proven, OEM-ready electric bicycle built for urban commuting in the Southeast Asia, Africa and South Asia markets.
Zielmärkte
Southeast AsiaAfricaSouth Asia
wangyeelectric-bicycleoemwholesale
Technical Specifications
| Motor | 1000W Dc permanent magnet brushless (直流永磁无刷) |
| Battery | 72V20Ah Lead-acid battery |
| Range | 90km |
| Top Speed | 45km/h |
| Charging Time | 72V3A |
| Payload | 140 kg |
| Weight | 90 kg |
| Dimensions | 1710mm×700mm×1100mm |
| Brake System | Front disc and back drum |
| Tires | 3.00-10 Vacuum tire |
| Colors | Black, White, Red, Blue |
Hauptmerkmale
Dc brushless vector (直流无刷矢量) controller
7° max climbing angle
730m seat height
130mm ground clearance
1230mm wheelbase
72V3A charger
DC 72V nominal voltage
